ATESS HPS 50 Hybrid Inverter with external CT

The HPS inverter range is a ALL – in one Hybrid inverter for commercial applications and support up to 4 units in parallel and it would be the perfect solution for every business out there.

An external CT can be connected to control export to non-essential loads

Different working modes (for more info on the working modes, please consult the user manual):

Peak-shaving
Time of use shifting
Back up
Off-grid
Product Features:
4 units can be paralleled giving a total AC output power of 200kW.
The PV array can be oversized by up to 50% of the rated AC output of the inverter.
Transformer based inverter - Capable of handling inductive loads effectively making it suitable for industrial based applications.
Touchscreen LCD user interface.
Diesel generator integration through the use of the Atess ATS (Automatic Transfer Switch)
All in one hybrid inverter.
Standard three-year warranty which can be extended up to seven years thus giving a maximum warranty period of 10 years.
Integrated export power limitation functionalities.

This product must be installed by a qualified electrician/technician. All installations must adhere to local wiring regulations and standards.

Weight: 604 kg
Rated Power: 50,000 W
Min PPT Voltage: 480 V
Max PPT Voltage: 800 V
DC Startup Voltage: 450 V
DC Shutdown Voltage: 450 V
Max Input Voltage: 1,000 V
Max DC Power: 75,000 W
Max AC Power (5 Minutes): 55,000 W
Surge AC Power (1 Second): 60,000 W
Max DC Current: 136 A
Max DC Inputs: 1
Has DC Fuses: 0
Connector: Round Post
Included Connectors: 0
Euro Efficiency: 95 %
Transformer: HF
MPPT Quantity : 1
Has Integrated DC Switch: Yes
